20 KW Three Phase On Grid Hybrid Inverter with WiFi App Monitoring

Sale

20 KW Three Phase On Grid Hybrid Inverter with WiFi App Monitoring

Name: 20 KW Three Phase On Grid Hybrid Inverter with WiFi App Monitoring
Brand: Solis
SKU: 87
Price: 316800.00 BDT
Availability: InStock

৳316,800~~৳360,000~~Save ৳43,200

In stock

Key features

Brand : Solis
Model : S6-EH3P20K-H
Three phase hybrid inverter
20 KW (20000 W) rated power
Maximum PV Input 32000 W
Connectivity : WiFi / App (Solis Cloud)
5 Years replacement warranty

100% genuineManufacturer warranty
Nationwide deliveryCash on delivery available
Expert supportSizing & installation help

Need a bulk quote or advice?Call our hotline 01740-303474

Combine solar generation with battery storage to power a three-phase home and cut reliance on the grid. The white wall-mounted steel enclosure has a front LCD panel with button controls, and all DC and AC wiring enters through sealed glands along the bottom edge. It suits large households and small commercial sites running high-voltage lithium or lead-acid battery banks.

Models	S6-EH3P20K-H
Input DC (PV side)
Recommended max. PV array size	40 kW
Max. usable PV input power	32 kW
Max. input voltage	1000 V
Rated voltage	600 V
Start-up voltage	160 V
MPPT voltage range	200 - 850 V
Max. input current	4 × 20 A
Max. current per DC input	20 A
Max. short circuit current	4 × 30 A
MPPT number / Max. input strings number	4 / 4
Battery
Battery type	Li-ion
Battery voltage range	120 - 800 V
Max. charge / discharge current	50 A
Number of battery port / Number of BMS port	1 / 1
Communication	CAN / RS485
Output AC (Grid side)
Rated output power	20 kW
Max. apparent output power	20 KVA
Rated grid voltage	3/N/PE, 220 V / 380 V, 230 V / 400 V
Rated grid frequency	50 Hz / 60 Hz
Rated grid output current	30.4 A / 28.9 A
Power factor	> 0.99 (0.8 leading - 0.8 lagging)
THDi	< 3%
Input AC (Grid side)
Max. input power	30 kW
Input voltage range	304 - 437 V / 320 - 460 V
Max. input current	45.6 A / 43.3 A
Output AC (Back-up)
Rated output power	20 kW
Max. apparent output power	1.6 time of rated power, 10 s
Back-up switch time ①	< 10 ms
Rated output voltage	3/N/PE, 220 V / 380 V, 230 V / 400 V
Rated frequency	50 Hz / 60 Hz
Rated output current	30.4 A / 28.9 A
Max. AC passthrough current	45.6 A / 43.3 A
THDv (@linear load)	< 3%
Input AC (Generator side)
Max. input power	20 kW
Rated input current	30.4 A / 28.9 A
Rated input voltage	3/N/PE, 220 V / 380 V, 230 V / 400 V
Rated input frequency	50 Hz / 60 Hz
Efficiency
Max. efficiency	97.7%
EU efficiency	97.5%
BAT charged by PV / AC max. efficiency	98.5% / 97.2%
Battery discharged efficiency	97.2%
Protection
Surge protection	DC Type II / AC Type II (Optional)
Output over current protection	Yes
Insulation resistance monitoring	Yes
Residual current detection	Yes
Integrated PV switch	Yes
DC reverse-polarity protection	Yes
Protection class / Over voltage category	I / II (PV and BAT), III (MAINS and BACKUP and GEN)
Integrated AFCI 2.0
Anti-islanding protection	Yes
General Data
Max. power per phase	40% rated power
Dimensions (W × H × D)	563 × 546 × 250 mm
Weight	35.2 kg
Inverter topology	Transformerless
Self-consumption	< 25 W
Operating temperature range	-25 ~ +60°C
Relative humidity	0 - 100%
Ingress protection	IP66
Noise emission (typical)	< 65 dB(A)
Cooling concept	Intelligent redundant fan-cooling
Max. operation altitude	2000 m
Grid connection standard	EN 50549-1/-10, VDE4105, CEI 0-21, CEI 0-16, NC-RFG TypeB, NRS 097-2-1, LTU-1, G99, PEA
Safety / EMC standard	IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4
Features
PV connection	MC4 connector
Battery connection	Lever terminal
AC connection	OT terminal
Display	7.0" LCD display & Bluetooth + APP
Communication interface	Standard: WIFI+LAN+Bluetooth, CAN-BMS, CAN-Parallel×2, RS485-Meter, RS485, DRM, DI, DO×3
