60 KW Three Phase On Grid Inverter with Wi-Fi App Monitoring

Sale

60 KW Three Phase On Grid Inverter with Wi-Fi App Monitoring

Name: 60 KW Three Phase On Grid Inverter with Wi-Fi App Monitoring
Brand: Solis
SKU: 102
Price: 442000.00 BDT
Availability: InStock

৳442,000~~৳520,000~~Save ৳78,000

In stock

Key features

Brand : Solis
Model : S5-GR60K
Inverter Type : Three phase On Grid Inverter
Rated Power: 60 KW (60000 W)
Maximum PV Input: 90000 W
Connectivity: Wi-Fi / App (Solis Cloud)
5 Years replacement warranty

100% genuineManufacturer warranty
Nationwide deliveryCash on delivery available
Expert supportSizing & installation help

Need a bulk quote or advice?Call our hotline 01740-303474

This three-phase on-grid string inverter turns up to 90 kW of PV input into 60 kW of grid-ready AC power for commercial solar plants. Its wall-mounted white and grey enclosure includes a front control panel and bottom cable entries for a tidy installation. It suits commercial rooftops and ground-mount PV systems that need flexible MPPT configuration, app monitoring, and a five-year warranty.

Models	S5-GC60K
Input DC
Max. input voltage	1100 V
Rated voltage	600 V
Start-up voltage	195 V
MPPT voltage range	180 - 1000 V
Max. input current	6 × 32 A
Max. short circuit current	6 × 40 A
MPPT number / Max. input strings number	6 / 12
Output AC
Rated output power	60 kW
Max. apparent output power	66 kVA
Max. output power	66 kW
Rated grid voltage	3/N/PE, 220 V / 380 V, 230 V / 400 V
Rated grid frequency	50 Hz / 60 Hz
Rated grid output current	91.2 A / 86.6 A
Max. output current	100.3 A
Power factor	> 0.99 (0.8 leading - 0.8 lagging)
THDi	< 3%
Efficiency
Max. efficiency	98.7%
EU efficiency	98.3%
Protection
DC reverse-polarity protection	Yes
Short circuit protection	Yes
Output over current protection	Yes
Surge protection	DC Type II / AC Type II
Grid monitoring	Yes
Anti-islanding protection	Yes
Temperature protection	Yes
Strings monitoring	Yes
I/V Curve scanning	Yes
Integrated AFCI 2.0	Optional
Multi peak scan	Yes
Integrated PID recovery	Optional ①
Integrated DC switch	Yes
General Data
Dimensions (W × H × D)	691 × 578 × 338 mm
Weight	53.7 kg
Topology	Transformerless
Self-consumption (night)	< 1 W
Operating ambient temperature range	-25 ~ +60°C
Relative humidity	0 - 100%
Ingress protection	IP66
Noise emission (typical)	< 55 dB(A)
Cooling concept	Intelligent fan-cooling
Max. operation altitude	4000 m
Grid connection standard	G99, VDE-AR-N 4105/VDE V 0124, EN 50549-1, VDE 0126/UTE C 15/VFR:2019, RD 1699/RD 244/UNE 206006/UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, EIFS 2018.2, IEC 62116, IEC 61727, IEC60068, IEC 61683, EN 50530
Safety / EMC standard	IEC 62109-1/-2, IEC62116 & IEC 61000-6-1/-2/-3/-4
Features
DC connection	MC4 connector
AC connection	OT terminal (max. 70 mm²)
Display	LCD
Communication	RS485, USB, Optional: Wi-Fi, GPRS
