10.24kWh 51.5V 200Ah LiFePO4 Battery 6000 Cycle Life
Sale

10.24kWh 51.5V 200Ah LiFePO4 Battery 6000 Cycle Life

৳184,000৳230,000Save ৳46,000
In stock

Key features

  • Brand: LVTOPSUN
  • Model: LVTS-512200-G3
  • Battery Type: Lithium Iron Phosphate (LiFePO₄)
  • Nominal Voltage: 51.2V
  • Rated Capacity: 200Ah
  • Nominal Energy: 10.24 kWh (10240Wh)
  • Operating Temperature: -20°C to +60°C
  • Cycle Life: Up to 6,000 cycles under specified test conditions
  • Warranty: 6 Years
  • Application: Solar Energy Storage, Home Backup Power, Telecom Systems, and Off-Grid Applications
  • 100% genuineManufacturer warranty
  • Nationwide deliveryCash on delivery available
  • Expert supportSizing & installation help
Need a bulk quote or advice?Call our hotline 01740-303474
The 10.24kWh battery stores solar energy and keeps home backup power running through outages. Its slim white metal case has a wall-mount bracket, front power indicator and a sealed maintenance-free build with built-in BMS protection. Suits homes, telecom sites and off-grid cabins needing dependable daily cycling.
ModelLVTS-512200-G3
Performance
Nominal Voltage51.2 Vdc
Nominal Capacity200 Ah
Battery Energy51.2 V,200 Ah, 10.24 kWh
Charge Voltage55.68~56.16 Vdc
Discharge Voltage45.6~56.16 Vdc
Maximum Charge Current100 A
Maximum Discharge Current170 A
Maximum Charge Power5120 W
Maximum Discharge Power1024 W
Short Circuit Current540 A
Communication
DisplayLED indicator+ LCD Display
CommunicationRS232, RS485, CAN
General Specification
Dimension (WxDxH mm)465x186x695 mm
Weight (Kg)83.5 kg
InstallationFloor Mount
Working Temperature(-20°C~60°C)
Storage Temperature≤25°C,12 months; ≤35°C,6 months; ≤45°C,3 months
Operating/Storage≤ 95%RH
Max Operating Altitude≤2000m
IP RatingIP20
Cell TechnologyLiFePO4, Lithium lron Phosphate
Cycle life6000 Cycles @ 90% DOD/25°C/0.5C，60% EOL
ScalabilityMax 63 batteries in parallel
Warranty6 years
Standard Compliance (more available upon request)
CertificatesCE, UN38.3
Ordering and Deliverable Part
Product ordering partLVTS-512200-G3 Battery (cable/wall mount included)
