Solar DC Cable 4 rm 1500V XLPO Double Insulated Tinned Copper
Sale

Solar DC Cable 4 rm 1500V XLPO Double Insulated Tinned Copper

৳132৳165Save ৳33
In stock

Key features

  • Brand: LEADER
  • Cable Size : 4 rm
  • Current carrying capacity : 57A
  • Product Type: Solar DC Photovoltaic Cable
  • Rated Voltage: DC 1500V
  • Operating Temperature: -40°C to +90°C
  • Life expectancy: ≥25 years
  • Water Resistant: Suitable for demanding outdoor environments
  • Standards: EN 50618 and IEC 62930
  • 100% genuineManufacturer warranty
  • Nationwide deliveryCash on delivery available
  • Expert supportSizing & installation help
Need a bulk quote or advice?Call our hotline 01740-303474
Carries DC power from solar panels to inverters with a 1500V rating for stable photovoltaic runs. The red and black XLPO jacket covers a flexible tinned stranded copper conductor in a round profile that bends easily around framing. Suits residential rooftop and commercial PV installations exposed to sun and weather.
ParameterValue
Cross section1 × 4 mm²
ApplicationSolar panel and photovoltaic system DC wiring
Rated voltageDC1500V
Conductor construction56/0.285 mm
Conductor diameter2.46 mm
Cable outer diameter5.6 mm
Current carrying capacity57 A
Test voltageAC 6.5KV, 50Hz, 5min
Working temperature-40℃ to +90℃
Max conductor temperature120℃
Short circuit temperature250℃, 5 seconds
Life expectancy≥25 years
Outer SheathE-Beam Cross-Linked XLPO
UV ResistantDesigned for outdoor solar installations
Maximum Conductor Temperature(+120°C)
Short-Circuit Temperature(Up to +250°C)
Mechanical StrengthHigh mechanical stability
ConductorTinned pure copper
Insulation MaterialE-Beam Cross-Linked XLPO
SheathXLPO (LSZH)
UV resistanceUV resistant for outdoor use
Fire performanceFlame retardant, LSZH
