16kWh 51.5V 314Ah LiFePO4 Battery 8000 Cycle Life
Sale

16kWh 51.5V 314Ah LiFePO4 Battery 8000 Cycle Life

৳272,000৳340,000Save ৳68,000
In stock

Key features

  • Brand: LVTOPSUN
  • Model: LVTS-512314-G4
  • Battery Type: Lithium Iron Phosphate (LiFePO₄)
  • Nominal Voltage: 51.2V
  • Rated Capacity: 314Ah
  • Nominal Energy: 16 kWh (16076.8Wh)
  • Operating Temperature: -20°C to +60°C
  • Cycle Life: Up to 8,000 cycles under specified test conditions
  • Warranty: 8 Years
  • Application: Solar Energy Storage, Home Backup Power, Telecom Systems, and Off-Grid Applications
  • 100% genuineManufacturer warranty
  • Nationwide deliveryCash on delivery available
  • Expert supportSizing & installation help
Need a bulk quote or advice?Call our hotline 01740-303474
This battery stores solar energy for home backup, off-grid and telecom systems, holding 16.07 kWh at 51.2V. Its white floor-standing cabinet sits on four castors, with a round LCD gauge, a slim vertical status light and an IP65 sealed housing. It suits homes and small commercial sites that need expandable storage, linking up to 63 units in parallel.
ModelLVTS-512314-G4
Performance
Nominal Voltage51.2 Vdc
Nominal Capacity314 Ah
Battery Energy51.2 V,314 Ah, 16.076 kWh
Charge Voltage55.68~56.16 Vdc
Discharge Voltage45.6~56.16 Vdc
Maximum Charge Current150 A
Maximum Discharge Current200 A
Maximum Charge Power8038.4 W
Maximum Discharge Power16076.8 W
Short Circuit Current540 A
Communication
DisplaySOC status indicator, LED indicator, LCD Display
CommunicationRS232, RS485, CAN
General Specification
Dimension (WxDxH mm)480x235x874 mm
Weight (Kg)120 kg
InstallationFloor Stand
Working TemperatureCharge 0°C~55°C Discharge-20°C~55°C
Storage TemperatureShort Term(within 1 month) -10°C~45°C
LongTerm(within 1 year)0°C~35°C
Operating/Storage≤ 95%RH
Max Operating Altitude≤2000m
IP RatingIP65
Cell TechnologyLiFePO4, Lithium lron Phosphate
Cycle life8000 Cycles @ 90% DOD/25°C/0.5C，60% EOL
Warranty10 years
Standard Compliance (more available upon request)
CertificatesCE, UN38.3
Ordering and Deliverable Part
Product ordering partLVTS-512314-G4 Battery
